Industrial Line · 95 Models
95 industrial Ethernet models — the non-PoE backbone line that aggregates cabinets, carries rings and feeds the PoE edge: managed, fiber-rich and built to the same industrial discipline.
Not every industrial port needs to deliver power. The backbone of an industrial network — the ring around a plant, the aggregation point of a road corridor, the link between cabinets — is carried by industrial Ethernet switches: data-only, fiber-rich, managed. ONV's line counts 95 models, from 2-port compact units to 52-port L3 managed flagships with 10G uplinks and 176 Gbps switching capacities.
These switches pair with the industrial PoE line: Ethernet models aggregate and transport, PoE models power the edge devices. Both lines share the catalogue's management tiers (Easy managed, L2+, L3) and fiber discipline, so a mixed design reads as one system. Where a port must power a camera directly, step across to the industrial PoE page; where it must simply survive and switch, this is the line.
Managed models from the 95-model industrial Ethernet catalogue (official product names).
| Model | Official product name |
|---|---|
| ONV-IPS36448FM | 10G uplink 44-port L2+ managed industrial Ethernet switch |
| ONV-IPS36028FM | 10G uplink 28-port L2+ managed industrial Ethernet switch |
| ONV-IPS38036FM | 10G uplink 36-port L3 managed industrial Ethernet switch |
| ONV-IPS38028FM | 10G uplink 28-port L3 managed industrial Ethernet switch |
| ONV-IPS38448FM | 10G uplink 44-port L3 managed industrial Ethernet switch |
| ONV-IPS38048FM | 10G uplink 52-port L3 managed industrial Ethernet switch |
| ONV-IPS38368FM | 10G uplink 36-port L3 managed industrial Ethernet switch |
| 2.5G series industrial switch | 2.5G series L3 managed industrial Ethernet switch |
| ONV-IPS56012FM | 10G 12-port L3 managed industrial Ethernet switch |
| ONV-IPS53168FMA | Gigabit 16-port Easy managed industrial Ethernet switch |
| ONV-IPS33052FM | Gigabit 52-port L2+ managed industrial Ethernet switch |
| ONV-IPS56028FM | 10G uplink 28-port L2+ managed industrial Ethernet switch |
The ONV-IPS36448FM is the line's flagship class: a 44-port L2+ managed industrial Ethernet switch with 10G uplinks, 176 Gbps capacity, a 32K MAC table and console management — backbone numbers, not access numbers.
| Parameter | Datasheet value |
|---|---|
| Switching capacity | 176 Gbps (non-blocking) |
| Forwarding rate | 119.04 Mpps @64byte |
| MAC address table | 32K |
| Buffer memory | 32M |
| Power input | Built-in PSU, AC100–240V, 60W |
| Console | 1 × console port |
| Standards | IEEE 802.3 / 802.3u / 802.3ab / 802.3z / 802.3ae / 802.3x |
Design the backbone top-down: ring or star, aggregate bitrate, and the failure you must survive. Ring designs want managed models end to end with consistent ring protocol support; aggregation points want 10G uplinks and SFP density; the edge of the backbone wants compact models with fiber uplinks. Verify each candidate's environmental ratings in its datasheet, exactly as with the PoE line.
Factory automation backbones, road and tunnel corridors, substations and energy sites, water and process plants — anywhere cabinets must be chained, ringed and monitored.
By port role: ports that power devices need PoE; ports that aggregate, ring or transport do not. Most industrial designs buy both — PoE at the device edge, Ethernet in the backbone.
The managed models are the ring candidates; ring protocol support is stated per model in its datasheet. Tell us your topology and we will confirm the ring-capable shortlist.
Send your port count, per-port power and uplink requirements — we reply with the exact models, datasheets and a quotation. MOQ and lead time are confirmed per model and order scope in the quotation.
Selection for the harshest sites.
