IoT Line · 4 Products
A pole or cabinet full of separate power supplies, sensors and controllers is a maintenance liability. The IoT intelligent box integrates them: multi-voltage power output, monitoring and remote control in one enclosure.
The IoT intelligent box line is ONV's answer to the messy reality of outdoor sites: a camera pole or roadside cabinet that needs several voltages (the featured model provides AC220V, AC24V and DC12V output groups), environmental sensing, power monitoring and the ability to restart a hung device remotely. The company's catalogue lists 4 products in the line: intelligent power boxes, a comprehensive intelligent O&M box, and the back-end management system software that ties deployed boxes into one operations view.
In networking terms these boxes are the site's IoT gateway layer: they aggregate the non-network elements of an unattended site — power, environment, device health — and report them over the network the switches provide. They are specified per site type (traffic pole, perimeter cabinet, remote sensor station), so this page is a starting point for a conversation rather than a click-to-buy catalogue.
The IoT Intelligent Box catalogue (official product names).
| Model | Official product name |
|---|---|
| ONV-IoT9000-DY-DG | IoT intelligent power box |
| ONV-IoT9000-CK-SI | IoT intelligent power box |
| ONV-IoT9000-ZH-HI-P | IoT comprehensive intelligent O&M box |
The ONV-IoT9000-DY-DG intelligent power box: frame-structure enclosure (600 × 440 × 300 mm), AC220V / AC24V / DC12V output groups with detection and remote control, and monitoring of environmental variables, power information and connected equipment — per its datasheet overview.
| Parameter | Datasheet value |
|---|---|
| Outputs | AC220V, AC24V and DC12V multiple voltage output groups |
| Functions | Environmental and power monitoring, detection and remote control of connected devices |
| Dimensions | 600 × 440 × 300 mm |
| Operating temperature | -20°C to +55°C |
| Certification (datasheet) | CE mark, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS |
Specify an IoT box from the site's device list: what must be powered (and at which voltages), what must be sensed (temperature, humidity, door, water, mains state), and what must be remotely switchable. The box is then matched — or the comprehensive O&M model selected where the site is complex — and the back-end system scoped by the number of sites under management. State the site type and device list in the inquiry; configurations are confirmed per project.
Traffic and surveillance poles, perimeter and gate cabinets, environmental and water monitoring stations, remote utility and pipeline sites — anywhere unattended equipment must report its own health.
No — it is the site's power and operations layer. It complements the switch (specified separately) by powering, monitoring and remotely controlling the site's devices, and reports through the network.
The catalogue includes a Backstage Management System alongside the boxes — the central software element for multi-site deployments. Scope and licensing are confirmed per project.
Send your port count, per-port power and uplink requirements — we reply with the exact models, datasheets and a quotation. MOQ and lead time are confirmed per model and order scope in the quotation.
